DT382W Rugged Tablet

Compact Windows computing is built for fieldwork.

Microsoft® Windows® 10/11 IoT Enterprise operating system

The DT382W rugged tablet delivers full Windows capability in a compact 8-inch platform designed for field, industrial, utility, public safety, and mobile applications. With an 800-nit touchscreen, Intel® N250 or Core™ N350 processor, NIST-compliant BIOS availability, and a hot-swappable battery system, it gives mobile teams dependable computing power in a smaller form factor.

Available options include 2D and long-range barcode scanning, NFC/RFID or UHF RFID, GPS, long-range Bluetooth, 4G LTE/AWS, and smart card/CAC access. With IP65 protection, MIL-STD-810H certification, HERO testing, and extended-temperature options, the DT382W is built for harsh environments and long shifts.

Ideal Uses for the DT382W Rugged Tablet

Vehicle-based operations
Field inspections and mobile data collection
Public safety and emergency response
Utility and energy field crews

Warehousing, inventory, and barcode applications
Mobile teams requiring smart card/CAC access
Outdoor work where sunlight-readable displays matter
Long shifts requiring hot-swappable battery power

Features

8” touchscreen; digital pen support
Intel_® N250 or Intel_® Core™ N350 processor
Microsoft_® Windows_® 11 IoT Enterprise operating system
NIST compliant BIOS available
IP65-rated for water and dust resistance
Wide operating temperature range
MIL-STD-810H for shock and vibration protection

Major Options

8 MP back camera
Barcode scanner or long-range 2D barcode scanner (up to 60 ft)
NFC/ RFID reader or UHF RFID reader
GPS module
Long-range BT
4G LTE/AWS
CAC card reader

*CAC card reader and SD slot cannot be built onto the same device.

Specifications

SYSTEM

CPU = DT382WN: Intel_® N250, 4-core (up to 3.80 GHz)
DT382WH: Intel_® Core™ N350, 8-core (up to 3.90 GHz)
RAM – 16GB
Storage – 512GB
Operating System – Microsoft_® Windows_® 11 IoT Enterprise
NIST Compliance – NIST compliant BIOS available
Display – 8″ LED-backlit, high-brightness 800 nits touchscreen
Display Resolution – 1280 x 800
Trusted Platform Module – fTPM 2.0
Fan/Fanless – Fanless
Buttons – 1 x power button, 2 x brightness buttons, 4 x programmable buttons
Speaker – Built-in speaker

NETWORK INTERFACE

WLAN – Wi-Fi 802.11ax, 2.4/5/6 GHz dual band
BT – 5.3

I/O PORTS

USB Port – 1 x USB 3.0, 1 x latest USB/charging (for data transmitting and charging)

Audio Jack – 1 (3.5 mm)

microSD Slot – 1 x microSD card slot

SIM Card Slot – 1 x Nano SIM slot

Dc-in Jack – 1

SD Slot (optional) – 1 x SD slot

MECHANICAL AND ENVIRONMENTAL

AC/DC Adapter – Input: 100 to 240V AC; Output: 19V DC, 3.42A
Battery Pack – 43W Hot-swappable battery (11.4V, 3800mAh)
(Optional) 60W Hot-swappable battery (11.4V, 5400mAh)
(Optional) 90W Hot-swappable battery (11.4V, 8000mAh)
Enclosure – ABS + PC Plastic
Dimensions (H x W x D) – 5.8 x 9.2 x 1.1 in/147.3 x 234 x 27.7 mm
Weight – 2.43 lbs/1.1 kg
Durability – IP65, MIL-STD-810H certified
Hazard of Electromagnetic Radiation to Ordnance (HERO) Testing – Yes
Regulatory – FCC Class B, IC, CE, RCM, RoHS compliant
Temperature – Operation*: -10°C to 60°C (14°F to 140°F)
Optional -30°C to 60°C (-22°F to 140°F)
Storage: -50°C to 70°C (-58°F to 158°F)
*For battery safety and optimal functionality and performance, the recommended usage temperature range is from -10°C to 45°C (14°F to 113°F)
Humidity – 0% to 90% non-condensing

MAJOR OPTIONS SPECS

Barcode Scanner – 2D barcode scanner (reads 1D and 2D)
Long range 2D barcode scanner (up to 60 ft)
Camera – 8 MP back camera with auto focus, white balance, gain control and exposure control
NFC/RFID Reader – HF 13.56 MHz, ISO 15693, 14443A(B) and 18000-3 mode 1
UHF RFID Reader – 865 to 928MHz, EPCglobal Class 1 Gen 2/ ISO 18000-6C; 16 ft (4.87m) reading distance
GNSS – GPS module
Smart Card/CAC Reader – Full-slot (reads ISO 7816 T=0, T=1); 1.8/3/5V smart card
Long Range BT – Class 1 BT (1000 ft)
Mobile Broadband – 4G LTE/AWS
