DT323RP Rugged Tablet

Slim, Rugged, Multi-functional Wireless Computing

Microsoft® Windows® 11 IoT Enterprise operating system

The DT323RP rugged tablet combines a 13.3-inch sunlight-readable touchscreen with Intel® Core™ i5/i7 processing in a durable platform built for demanding field, vehicle, industrial, and mobile applications. With Windows 11 IoT Enterprise, digital pen support, a hot-swappable battery system, and quick-access SSD storage, it delivers full computing capability for teams working beyond the office.

Available options include 4G LTE/5G, GPS, 2D barcode scanning, cameras, and smart card/CAC access. With IP65 protection, MIL-STD-810H certification, HERO testing, and operation across a wide temperature range, the DT323RP is built for long shifts and harsh environments.

Ideal Uses for the DT323RP Rugged Tablet

Vehicle-based operations
Field inspections and mobile data collection
Public safety and emergency response
Utility and energy field crews

Warehousing, inventory, and barcode applications
Mobile teams requiring smart card/CAC access
Outdoor work where sunlight-readable displays matter
Long shifts requiring hot-swappable battery power

Features

13.3” sunlight-readable touchscreen, digital pen support
Intel_® Core™ i5/i7 processor
Microsoft_® Windows_® 11 IoT Enterprise operating system
NIST compliant BIOS available
IP65-rated for water and dust resistance
MIL-STD-810H for shock and vibration protection
Quick access SSD

Major Options

5 MP front camera and 8 MP rear camera
2D barcode scanner (reads 1D and 2D)
GPS mdule
4G LTE/5G
Smart card/CAC reader

Specifications

SYSTEM

CPU – Intel_® Core™ i5-1335U, 10-core, up to 4.6 GHz
Intel_® Core™ i7-1355U, 10-core, up to 5.0 GHz
RAM – 8GB
Storage – 512GB to 2TB flash
*Support quick access SSD function to easily replace the SSD without opening the back cover
Operating System – Microsoft_® Windows_® 11 IoT Enterprise
NIST Compliance – NIST compliant BIOS available
Display – 13.3” LED-backlit, sunlight-readable 1000 nits touchscreen
Display Resolution – 1920 x 1200
Microphone – Built-in microphone
Speaker – Built-in speaker
Buttons – 1 x power button; 2 x brightness buttons; 5 x programmable buttons

NETWORK INTERFACE

WLAN – Wi-Fi 802.11ax, 2.4/5/6 GHz three band
BT – 5.3

I/O PORTS

USB Port – 1 x USB 3.0, 1 x latest USB/charging
Headset Jack – 1 (3.5 mm)
Ethernet Port – 1 x Ethernet 10/100/1000MB Base-T LAN
DC-in Jack – 1

MECHANICAL AND ENVIRONMENTAL

AC/DC Adapter – Input: 100 to 240V AC; Output: 19V DC, 3.42A
Battery Pack – 43W Hot-swappable battery (11.4V, 3800mAh)
(Optional) 60W Hot-swappable battery (11.4V, 5400mAh)
(Optional) 90W Hot-swappable battery (11.4V, 8000mAh)
Enclosure – ABS + PC plastic and magnesium-aluminum alloy
Dimensions (H x W x D) – 12.8 x 10.7 x 0.8 in/325 x 273.5 x 20 mm
Weight – 3.81 lbs/1.72 kg
Durability – IP65, MIL-STD-810H certified
Hazard of Electromagnetic Radiation to Ordnance (HERO) Testing – Yes
Regulatory – FCC Class B, CE, RoHS compliant
Temperature – Operation*: -10°C to 60°C (14°F to 140°F)
*For battery optimal functionality and performance, the recommended usage temperature range is from 0°C to 50°C (32°F to 122°F)
Storage: -55°C to 70°C (-67°F to 158°F)
Humidity – 0% to 90% non-condensing

MAJOR OPTIONS SPECS

Barcode Scanner – 2D barcode scanner (reads 1D and 2D)
Camera – 5 MP front camera and 13 MP rear camera
GNSS – GPS
Mobile broadband – 4G LTE/5G
Smart Card/CAC Reader – Half-slot (supports ISO 7816 T=0, T=1); 1.8V/3V/5V smart card
