The LT360PA Rugged Laptop integrates a 13.3-inch touchscreen, Intel Core Ultra 5/7 processing, and a full-size keyboard in a rugged platform built for demanding field and mobile environments. They feature built-in Wi-Fi, an optional 2D barcode scanner, a smart card/ CAC reader, night vision screen, RFID, and other data capture options. These laptops offer advanced identity verification for secure data access. The optional night-vision display supports MIL-STD-3009 Class B NVIS mode for readable operation in low-light environments and compatibility with NVGs. Rated IP65 and compliant with MIL-STD-810H/461G, these powerful rugged laptops support a wide temperature range, ensuring reliable operation in harsh, mission-critical environments.
LT360PA Rugged Laptop
Compact, Purpose-Built for Mission-Critical Environments
Microsoft® Windows® 11 IoT Enterprise operating system
Ideal Uses for the LT360PA Rugged Laptop
- Public safety
- Utility and energy operations
- Industrial fieldwork
- Vehicle-based operations
- Secure mobile computing
- Mission-critical applications
Features
- 13.3″ high-brightness touchscreen; digital pen support
- Intel® Core™ Ultra 5/7 processor
- Microsoft® Windows® 11 IoT Enterprise operating system
- Dual color backlit keyboard with multi-touch pad
- Robust design with antimicrobial coating
- Hot-swappable batteries for 24/7 operation
- Modular design to easily replace the batteries
- IP65-rated for water and dust resistance
- MIL-STD-810H for shock and vibration protection
- MIL-STD-461G for EMI and EMC tolerance
- 2 MP IR camera with privacy cover; supports Windows Hello
- Energy Star 9.0 certified
Major Options
- 4K (3840 x 2160) resolution screen
- MIL-STD-3009 class B night vision screen
- 4G LTE
- 2D barcode scanner
- CAC card reader
- GPS module
- RFID
- Additional 1x latest USB/charging and 1x RJ45, or SFP connector or 24-pin fischer connector
Specifications
- CPU – Intel® Core™ Ultra 5 processor 225H, 14-core (up to 4.9 GHz)
Intel® Core™ Ultra 7 processor 255H, 16-core (up to 5.1 GHz) - RAM – Ultra 5: 16GB LPDDR5
Ultra 7: 16GB to 32GB LPDDR5 - Storage – 256GB to 2TB SSD
- Operating System – Microsoft® Windows® 11 IoT Enterprise
- NIST Compliance – NIST compliant BIOS available
- Microphone – Built-in microphone array
- Speaker – Built-in speaker
- Camera – 2 MP IR camera with privacy cover; supports Windows Hello
- Buttons – 1 x power button, 1 x 2D scanner or NVIS mode trigger button, 2 x brightness touch buttons, 2 x programmable touch buttons
- Screen Size – 13.3″ touchscreen
- Resolution – 1920 x 1080, or 3840 x 2160 (optional)
- Luminance – Standard high-brightness (1000 nits)
Option 1 night vision screen – daylight mode: 800 nits; NVIS mode: 0 to 20 nits
Option 2 night vision screen – daylight mode: 800 nits; NVIS mode: 0 to 0.7 nits
- Keys – QWERTY, full row of F1 to F12 function keys; Keys for Copilot / Windows shortcuts, media controls, screen brightness
- Backlight – Yes
- Touch Pad – Multi-touch
- WLAN – Wi-Fi 802.11ax 2.4/5/6 Ghz three band
- BT – 5.4
- USB Port – 2 x USB-A, 1 x latest USB/charging (optional: additional 1 x latest USB/charging)
- Ethernet – 1 x 10/100/1000 MB Base-T RJ45 LAN (optional: additional 1 x RJ45)
- Audio Jack – 1 (3.5 mm)
- HDMI-out – 1
- 24-pin Fischer Connector (Optional) – 1
- SFP Connector (Optional) – 1
- DC-in Jack – 1
- SD Card Reader – 1
- Nano SIM Card Slot – 1
- AC/DC Adapter – Input: 100-240V AC; Output: 19V, 120W
- Battery Pack – 2 x Hot-swappable batteries (11.4V, 5400mAh)
2 x Hot-swappable batteries (11.4V, 8000mAh) (optional) - Enclosure – ABS + PC plastic and magnesium-aluminum alloy with antimicrobial coating
- Kensington Lock – 1
- Dimensions (H x W x D) – 1.22 x 13.66 x 9.84 in/31 x 347 x 250 mm
- Weight – 6.21lbs/2.82 kg (with battery)
- Durability – IP65, MIL-STD-810H and MIL-STD-461G certified
- Regulatory – FCC Class B, CE, CB, RoHS, EPEAT, Cyber, Energy Star 9.0 compliant
- Temperature – Operation: -10°C to 60°C (14°F to 140°F), optional -30°C to 60°C (-22°F to 140°F)
storage: -55°C to 70°C (-67°F to 158°F) - Humidity – 0% to 90%, non-condensing
- Night Vision Screen Luminance
Option 1: Daylight mode: 800 nits; NVIS mode: 0 to 20 nits. MIL-STD-3009 class B compliant, providing clear readability of the display with the naked eye in dark environments; does not interfere with NVGs
Option 2: Daylight mode: 800 nits; NVIS mode: 0 to 0.7 nits. MIL-STD-3009 class B compliant, providing clear readability of display with NVGs in dark environments - Mobile Broadband – 4G LTE
- GNSS – GPS
- Barcode Scanner – 2D barcode scanner (reads 1D and 2D)
- Smart Card/CAC Reader – Full-slot (reads ISO 7816 T=0, T=1); 1.8/3/5V smart card
- RFID Reader – Dual frequency (reads 125 KHz and 13.56 MHz credentials)
LT360PA RUGGED LAPTOP
Built to perform. Specifications to prove it.
Available through M59 Technologies, this rugged hardware is designed for field, vehicle, industrial, public safety, utility, and other demanding work environments where reliability matters.
Review the specifications above for system details, connectivity, I/O ports, environmental ratings, and available configurations. For complete technical information, download the product datasheet below.
Know the hardware. Know the capabilities. Put it to work.
