DT302PA Rugged Tablet

Slim, Rugged, Multi-functional Wireless Computing

Microsoft® Windows® 11 IoT Enterprise operating system

The DT302RP packs full Windows capability into a rugged 10.1-inch tablet designed for crews who need a smaller, lighter device without sacrificing performance. Its sunlight-readable touchscreen, Intel Core processor, and hot-swappable battery make it a strong fit for field, vehicle, and mobile operations where equipment must keep working through long shifts and rough conditions.

Available options include barcode scanning, GPS, 4G LTE, cameras, and smart card/CAC access, allowing the DT302RP to be configured around the way your team works. It is IP65 rated and MIL-STD-810H/461G certified for demanding environments.

Ideal Uses for the DT302PA Rugged Tablet

Vehicle-based operations
Field inspections and mobile data collection
Public safety and emergency response
Utility and energy field crews

Warehousing, inventory, and barcode applications
Mobile teams requiring smart card/CAC access
Outdoor work where sunlight-readable displays matter
Long shifts requiring hot-swappable battery power

Features

10.1″ LED-backlit, sunlight-readable 1000 nits touchscreen digital pen support
Intel_® Core™ Ultra 5/7 processor
Microsoft_® Windows_® 11 IoT Enterprise operating system
NIST compliant BIOS available
Hot-swappable battery for 24/7 operation
Built-in microphone and speaker
Detachable keyboard option for 2-in-1 applications
IP65 rated, MIL-STD-810H and MIL-STD-461G certified
Quick access SSD
Energy Star 9.0 certified

Major Options

5 MP front camera and 13 MP back camera
2D barcode scanner (reads 1D and 2D)
GPS module
4G LTE
Smart card/CAC reader
NFC/RFID reader

*4G LTE module, 2D scanner and GPS cannot be built onto same device.

Specifications

SYSTEM

CPU – Intel_® Core™ Ultra 5 processor 225U, 12 core (up to 4.80 GHz)
Intel_® Core™ Ultra 7 processor 255U, 12 core (up to 5.20 GHz)
RAM – Ultra 5: 16GB LPDDR5
Ultra 7: 32GB to 64GB LPDDR5
* The memory is embedded. Alternative configurations are available by special order with MOQ
Storage – 512GB to 2TB
*Support quick access SSD function to easily replace the SSD without opening the back cover
Operating System – Microsoft_® Windows_® 11 IoT Enterprise
NIST Compliance – NIST compliant BIOS available
Display – 10.1″ LED-backlit, sunlight-readable 1000 nits touchscreen
Display Resolution – 1920 x 1200
Microphone – Built-in microphone
Speaker – Built-in 2W speaker

NETWORK INTERFACE

WLAN – Wi-Fi 802.11ax, 2.4/5/6 GHz three band
BT – 5.3

I/O PORTS

USB Port – 1 x USB3.2 (Type-A), 1 x USB3.2 latest USB/charging
Headset Jack – 1 (3.5 mm)
Ethernet Port – 1 x Ethernet 10/100/1000MB Base-T LAN
DC-in Jack – 1
24-pin Fischer Minimax Connector (optional) – 1 x USB2.0, COM port, RJ45, Power 5A (in), and Power 2A (out)

MECHANICAL AND ENVIRONMENTAL

AC/DC Adapter – Input: 100 to 240V AC; Output: 19V DC, 3.42A (65W)
Battery Pack – 43W Hot-swappable battery (11.4V, 3800mAh)
(Optional) 60W Hot-swappable battery (11.4V, 5400mAh)
(Optional) 90W Hot-swappable battery, (11.4V, 8000mAh)
Enclosure – ABS + PC plastics and magnesium-aluminum alloy with anti-microbial coating
Dimensions (H x W x D) – 7.7 x 10.71 x 0.79 in/195.6 x 272 x 20 mm
Weight – 3 lbs/1.32 kg
Durability – IP65, MIL-STD-810H and MIL-STD-461G certified
Regulatory – CE, FCC Class B, IC, CB, RCM, IEC 60601-1, IEC62680, EPEAT, Energy star 9.0
Temperature – Operation: -10°C to 60°C (14°F to 140°F);
Storage: -50°C to 70°C (-58°F to 158°F)
Humidity – 0% to 90% non-condensing

MAJOR OPTIONS SPECS

Barcode Scanner – 2D barcode scanner (reads 1D and 2D)
Camera – 5 MP front camera and 13 MP back camera
GNSS – GPS
Mobile Broadband – 4G LTE
Smart Card/CAC Reader – Half-slot (supports ISO 7816 T=0, T=1); 1.8V/3V/5V smart card
NFC/RFID Reader – HF 13.56 MHz, ISO 15693, 14443A(B) and 18000-3 Mode 1
