DA381ND Android Rugged Tablet

Lightweight Android Performance for Demanding Field Work

Android 13 operating system

The DA381ND Rugged Tablet combines an 8-inch, 1000-nit touchscreen with Android 13 and Qualcomm 8-core performance in a compact, rugged tablet weighing just 1.28 pounds. It is designed for crews who need a highly portable device that can handle field use, outdoor visibility, and demanding mobile work without adding unnecessary bulk.

With Wi-Fi 6, Bluetooth 5.2, front and rear cameras, programmable buttons, and a hot-swappable battery, the DA381ND is built for everyday field mobility. An optional waterproof Fischer MiniMax connector expands its usefulness in specialized industrial and vehicle-based applications. IP65 and MIL-STD-810H ratings support reliable operation in harsh environments.

Ideal Uses for the DA381ND

Field inspections and mobile data collection
Utility and energy crews
Industrial and plant operations
Vehicle-based applications

Outdoor work which requires a high-brightness display
Mobile teams that need a lightweight device
Specialized applications requiring the Fischer MiniMax connector
Long-shift field work with hot-swappable battery power

Features

8″ LED 1000 nits touchscreen, capacitive stylus support
Qualcomm_® 8-core processor
Android 13 operating system
5 MP front camera and 13 MP rear camera
Hot-swappable battery pack
IP65-rated for water and dust resistance
MIL-STD-810H for shock and vibration protection
Wide operating temperature range

Major Options

Waterproof 24-pin Fischer MiniMax connector

Specifications

SYSTEM

CPU – Qualcomm_® 8-core (1.9 GHz to 2.7 GHz)
Storage and RAM – 256GB flash with 12GB RAM
Operating System – Android 13
Security Features – ARM_® TrustZone_® (built-in)
Display – 8” LED 1000 nits touchscreen
Display Resolution – 1400 x 720
Camera – 5 MP front camera and 13 MP rear camera
Microphone – Built-in microphone
Speaker – Built-in speaker
Buttons – 1 x power button; 1 x day/night vision switch; 2 x programmable buttons

NETWORK INTERFACE

WLAN – \Wi-Fi 802.11ax, 2.4/5/6 GHz three band
BT – 5.2

I/O PORTS

USB Port – 1 x latest USB/charging
24-pin Fischer Minimax Connector – (Optional) Ethernet, USB-3.2 5G/USB2.0, and power 5-6A (in) and power 2A (out)/ground/URAT

MECHANICAL AND ENVIRONMENTAL

AC/DC Adapter – Input: 100 to 240V AC; Output: 19V DC, 3.25A
Battery Pack – 23W Hot-swappable battery (7.6V, 3100mAh)
Enclosure – ABS + PC plastic and magnesium-aluminum alloy
Dimensions (H x W x D) – 5.87 x 7.91 x 0.89 in/149 x 201 x 22.6 mm
Weight – 1.28 lbs/0.58 kg
Vibration and Shock Resistance – MIL-STD-810G
Water and Dust Resistance – IP65 and MIL-STD-810H
Regulatory – CE, FCC Class B, and RoHS compliant
Temperature – Operation: -10°C to 50°C (14°F to 122°F);
Storage: -55°C to 70°C (-67°F to 158°F)
Humidity – 0% to 90% non-condensing
